FPV Camera Foxeer Micro Cat 4 1200TVL 1/3 CMO Black

Foxeer Micro Cat 4 is a premium low-light analog FPV camera featuring a 1/3" Sony CMOS sensor, 1200TVL resolution, and ultra-sensitive Starlight technology for clear, detailed images in near-dark conditions. With switchable 4:3/16:9 aspect ratios, PAL/NTSC formats, wide dynamic range (WDR), and low latency under 10 ms, it delivers excellent performance for night flying, freestyle, and long-range FPV.

Features:
- Exceptional in extremely low-light conditions thanks to ~0.00001 Lux sensitivity
- Sharp 1200 TVL resolution with selectable aspect ratio (4:3 or 16:9)
- Balanced function for both night-time and daylight FPV flying
- Minimal latency (<10 ms), flexible voltage input, and rich OSD features
- Lightweight and compact design ideal for tight build spaces

Specifications:
Sensor Type: Sony 1/3" CMOS Sensor
Scale: 4:3(Default)/16:9 Switchable
Tv System: PAL(Default)/NTSC Switchable
Resolution: 1200TVL
Lens: M12 2.1mm Low Light Lens
FOV:
- 4:3 FOV-H: 95°, FOV-V: 72°, FOV-D:120°
- 16:9 FOV-H: 95°, FOV-V: 53°, FOV-D:110°
Shutter Speed: PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec
Video Output: CVBS Analog Signal
Minimum Illumination: 0.00001Lux
White Balance: Auto
DNR: 3DNR
WDR: 100dB
DAY/NIGHT: EXT/Auto/Color/B&W
Flight OSD: Voltage/Cam Title/Time
Input Voltage: 5V~20V
Language:ENGLISH / 中文/ РУССКИЙ/ ESPANOL/ ITALIANO/ FRANCAIS/ POLSKIM/  PORTUGUES / 日本语 / EAAHNIKA
Working Temperature: -10°~50°C RH90% MAX
Working Humidity: 20~80%
Storage Temperature: -20°~70°C
Consumption: 95mA±15% @ DC12V
Dimension: 19x19mm
Weight: 11.8g(Exclude cable)

Package includes:
1x Foxeer Cat 4 Camera
4x Screws
4x Gasket Ring
1x OSD Board
1x 2pin OSD Cable
1x Servo Cable
